201
REVO-E Heat pump 2 Technical specifications
2 Technical specifications
The technical specifications, provided that there are no
limit values given, comply with the standard tolerances for
air-conditioning systems of ±10% for an ambient temper-
ature of +20° C and nominal voltage.
Table 201 Technical specifications
1
) T
ambient
= 35 °C, T
cabin
= 40 °C
2
) T
ambient
= 5 °C , T
cabin
= 20 °C
3
) Version installed two times in articulated vehicle
REVO-E heat pump
REVO-E HP+ REVO-E HP
11123865_
3
11120816_
Application Volvo E-Bus 2nd
Generation
(from 2018)
Volvo E-Bus 1st
Generation
(till 2018)
Operating range heat pump [°C] ≥ -5 ≥ 3
Cooling capacity [kW]
1
25
Heating capacity in heat-pump-mode [kW]
2
16
Heating capacity coolant circuit [kW] 40
Air volume [m³/h] 6960
Current consumption [A]
(24 V DC)
maximum (all 100 %) 85
nominal (condenser 80%, evaporator 70%) 55
regulated
(the temperature in the passenger compartment is at set
point)
11
Current consumption [A]
(600 V DC)
maximum (compressor speed at 50Hz) 22
regulated
(the temperature in the passenger compartment is at set
point 25°C - ambient temperature 35 °C, reduced com-
pressor speed)
9
Weight [kg] 272
Dimensions (length x wide x height) [mm] 2802x2091x406
Operation voltage range [V DC] 450-750
Refrigerant R134A
Filling capacity w/o front box[kg] 5
Filling capacity with front box [kg] 5.5
