Main
menu
Number
of
menus
Description
ANSI
code
Note
f<<
4
2nd underfrequency stage
81L
4
dfdt
3
Rate of change of frequency
(ROCOF) stage
81R
4
Prg1
3
1st programmable stage
4
Prg2
3
2nd programmable stage
4
Prg3
3
3rd programmable stage
4
Prg4
3
4th programmable stage
4
Prg5
3
5th programmable stage
4
Prg6
3
6th programmable stage
4
Prg7
3
7th programmable stage
4
Prg8
3
8th programmable stage
4
If2>
3
Second harmonic O/C stage
51F2
4
CBFP
3
Circuit breaker failure
protection
50BF
4
CBWE
4
Circuit breaker wearing
supervision
4
AR
15
Auto-reclose
79
CTSV
1
CT supervisor
4
VTSV
1
VT supervisor
4
ArcI>
4
Optional arc protection stage
for phase-to-phase faults and
delayed light signal.
50ARC
4
ArcIo>
3
Optional arc protection stage
for earth faults. Current input
= I01
50NARC
4
OBJ
11
Object definitions
5
Lgic
2
Status and counters of user's
logic
1
CONF
10+2
Device setup, scaling etc.
6
Bus
13
Serial port and protocol
configuration
7
Diag
6
Device selfdiagnosis
Notes
1
Configuration is done with VAMPSET
2
Recording files are read with VAMPSET
3
The menu is visible only if protocol "ExternalIO" is selected for one
of the serial ports. Serial ports are configured in menu "Bus".
4
The menu is visible only if the stage is enabled.
5
Objects are circuit breakers, disconnectors etc.. Their position or
status can be displayed and controlled in the interactive mimic
display.
6
There are two extra menus, which are visible only if the access level
"operator" or "configurator" has been opened with the corresponding
password.
7
Detailed protocol configuration is done with VAMPSET.
