6.2.6. DNP 3.0
The device supports communication using DNP 3.0 protocol.
The following DNP 3.0 data types are supported:
 binary input
 binary input change
 double-bit input
 binary output
 analog input
 counters
Additional information can be obtained from the ―DNP 3.0
Device Profile Document‖.
DNP 3.0 communication is activated via menu selection. RS-
485 interface is often used but also RS-232 and fibre optic
interfaces are possible.
Parameters
Parameter
Value
Unit
Description
Set
bit/s
4800
9600 (default)
19200
38400
bps
Communication speed
Set
Parity
None (default)
Even
Odd
Parity
Set
SlvAddr
1  65519
An unique address for
the device within the
system
Set
MstrAddr
1  65519
255=default
Address of master
Set
LLTout
0  65535
ms
Link layer confirmation
timeout
Set
LLRetry
1  255
1=default
Link layer retry count
Set
APLTout
0  65535
5000=default
ms
Application layer
confirmation timeout
Set
CnfMode
EvOnly (default)
All
Application layer
confirmation mode
Set
DBISup
No (default)
Yes
Double-bit input support
Set
SyncMode
0  65535
s
Clock synchronization
request interval.
0 = only at boot
Set
Set = An editable parameter (password needed)
