9.1.5. Alarm contacts
Number of contacts:
3 change-over contacts (relays A1, A2 and A3)
2 making contacts (relays A4 and A5)
1 change-over contact (IF relay)
Rated voltage
250 V ac/dc
Max. make current, 4s at duty cycle 10%
15 A
Continuous carry
5 A
Breaking capacity, AC
2 000 VA
Breaking capacity, DC (L/R=40ms)
at 48 V dc:
at 110 V dc:
at 220 V dc
1,3 A
0,4 A
0,2 A
Contact material
AgNi 0.15 gold plated
AgNi 90 / 10
Terminal block
Maximum wire dimension
- Phoenix MVSTBW or equivalent
2.5 mm
2
(13-14 AWG)
9.1.6. Local serial communication port
Number of ports
1 on front and 1 on rear panel
Electrical connection
RS 232 in the front
RS 2320 with VCM-TTL (standard)
RS-485 with VCM 485-2 or VCM 485-4
Plastic fibre with VCM-fibre (option)
Glass fibre with VCM-fibre (option)
Data transfer rate
2 400 – 38 400 kb/s
9.1.7. Remote control connection
Number of ports
1 on rear panel
Electrical connection
TTL with VCM TTL (standard)
RS 485 with VCM 485 – 4 (option)
RS 232 with VCM TTL (standard)
Plastic fibre connection with VCM fiber (option)
Glass fibre connection with VCM fiber (option)
Data transfer rate
1 200 – 19 200 kb/s
Protocols
ModBus, RTU master
ModBus‘ RTU slave
SpaBus, slave
IEC 60870-5-103
IEC 61870-5-101
ProfiBus DP (option, with external module)
DNP 3.0
9.1.8. Ethernet connection
Number of ports
1
Electrical connection
Ethernet RJ-45 (Ethernet 10-Base-T)
Protocols
VAMPSET
Modbus TCP
IEC 61850
Data transfer rate
10 Mb/s
