VAMP 259 - Auxiliary Voltage; Digital Inputs; Trip Contacts

Technical description
9 Technical data
9.1 Connections
VM259.EN007
VAMP 24h support phone +358 (0)20 753 3264
279
9.1.2. Auxiliary voltage
Type A
Type B
Voltage range U
aux
40 - 265 V ac/dc
18...36 Vdc
Note! Polarity.
X3:17= positive (+)
X3:18= negative (-)
Start-up peak (DC)
110V
220V
15A with time constant of 1ms
25A with time constant of 1ms
Power consumption
< 7 W (normal conditions)
< 15 W (output relays activated)
Max. permitted interruption time
>50 ms (110 V dc)
Terminal block:
Maximum wire dimension:
- Phoenix MVSTBW or equivalent
2.5 mm
2
(13-14 AWG)
9.1.3. Digital inputs
Internal operating voltage
Number of inputs
6
Internal operating voltage
48 V dc
Current drain when active (max.)
approx. 20 mA
Current drain, average value
< 1 mA
Terminal block:
Maximum wire dimension:
- Phoenix MVSTBW or equivalent
2.5 mm
2
(13-14 AWG)
External operating voltage
Number of inputs
12/24/16 (depends on the ordering code)
external operating voltage
18 V…265 V dc
Current drain
approx. 2 mA
Terminal block:
Maximum wire dimension:
- Phoenix MVSTBW or equivalent
2.5 mm
2
(13-14 AWG)
9.1.4. Trip contacts
Number of contacts
4/8/14 (depends on the ordering code)
Rated voltage
250 V ac/dc
Continuous carry
5 A
Make and carry, 0.5 s
Make and carry, 3s
30 A
15 A
Breaking capacity, DC (L/R=40ms)
at 48 V dc:
at 110 V dc:
at 220 V dc
5 A
3 A
1 A
Contact material
AgNi 90/10
Terminal block:
Maximum wire dimension:
- Phoenix MVSTBW or equivalent
2.5 mm
2
(13-14 AWG)
