VAMP 259 - Virtual Inputs and Outputs

Technical description
5 Control functions
5.3 Virtual inputs and outputs
VM259.EN007
VAMP 24h support phone +358 (0)20 753 3264
205
Common
input
Input group
Wetting voltage
On
Off
X7:7
X7: 1-6 (DI 7-12)
≥18 V dc or ≥50 Vac
10 V dc or 5 V ac
X7:14
X7: 8-13 (DI 13-18)
≥18 V dc or ≥50 Vac
10 V dc or 5 V ac
X8:3
X8: 1-2 (DI 21-22)
≥18 V dc or ≥50 Vac
10 V dc or 5 V ac
X8:6
X8: 4-5 (DI 23-24)
≥18 V dc or ≥50 Vac
10 V dc or 5 V ac
X8:9
X8: 7-8 (DI 25-26)
≥18 V dc or ≥50 Vac
10 V dc or 5 V ac
X8:12
X8: 10-11 (DI 27-28)
≥18 V dc or ≥50 Vac
10 V dc or 5 V ac
For input group X8: 13-20 (DI 29-32), it is possible to use
different control voltages individually.
The digital input signals can also be used as blocking signals
and control signals for the output relays.
5.3. Virtual inputs and outputs
There are four virtual inputs and six virtual outputs. The four
virtual inputs acts like normal digital inputs. The state of the
virtual input can be changed from display, communication bus
and from VAMPSET. For example setting groups can be
changed using virtual inputs.
Parameters of virtual inputs
Parameter
Value
Unit
Description
Set
VI1 ... VI4
0
1
Status of virtual input
Events
On
Off
Event enabling
Set
Parameter
Value
Unit
Description
Set
NAMES for VIRTUAL INPUTS (editable with VAMPSET only)
Label
String of
max. 10
characters
Short name for VIs on the
local display
Default is "VIn", n=1...4
Set
Description
String of
max. 32
characters
Long name for VIs.
Default is
"Virtual input n", n=1...4
Set
Set = An editable parameter (password needed)
The six virtual outputs do act like output relay
s, but there are no physical contacts. Virtual outputs are shown
in the output matrix and the block matrix. Virtual outputs can
be used with the user's programmable logic and to change the
active setting group etc.
