Setting parameters of AR function:
Parameter
Value
Unit
Default
Description
ARena
ARon; ARoff
-
ARon
Enabling/disabling the
autoreclose
Block
None,
any digital
input,
virtual input
or virtual
output
-
-
The digital input for block
information. This can be used,
for example, for Synchrocheck.
AR_DI
None,
any digital
input,
virtual input
or virtual
output
-
-
The digital input for toggling
the ARena parameter
AR2grp
ARon; ARoff
-
ARon
Enabling/disabling the
autoreclose for group 2
ReclT
0.02 … 300.00
s
10.00
Reclaim time setting. This is
common for all the shots.
ARreq
On; Off
-
Off
AR request event
ShotS
On; Off
-
Off
AR shot start event
ARlock
On; Off
-
Off
AR locked event
CritAr
On; Off
-
Off
AR critical signal event
ARrun
On; Off
-
Off
AR running event
FinTrp
On; Off
-
Off
AR final trip event
ReqEnd
On; Off
-
Off
AR end of request event
ShtEnd
On; Off
-
Off
AR end of shot event
CriEnd
On; Off
-
Off
AR end of critical signal event
ARUnl
On; Off
-
Off
AR release event
ARStop
On; Off
-
Off
AR stopped event
FTrEnd
On; Off
-
Off
AR final trip ready event
ARon
On; Off
-
Off
AR enabled event
ARoff
On; Off
-
Off
AR disabled event
CRITri
On; Off
-
On
AR critical final trip on event
AR1Tri
On; Off
-
On
AR AR1 final trip on event
AR2Tri
On; Off
-
On
AR AR2 final trip on event
CRITri
On; Off
-
On
AR critical final trip off event
AR1Tri
On; Off
-
On
AR AR1 final trip off event
AR2Tri
On; Off
-
On
AR AR2 final trip off event
Shot settings
DeadT
0.02 … 300.00
s
5.00
The dead time setting for this
shot. This is a common setting
for all the AR lines in this shot
AR1
On; Off
-
Off
Indicates if this AR signal
starts this shot
AR2
On; Off
-
Off
Indicates if this AR signal
starts this shot
Start1
0.02 … 300.00
s
0.02
AR1 Start delay setting for this
shot
