6.1 Communication ports
6 Communication
Technical description
220
VAMP 24h support phone +358 (0)20 753 3264
VM259.EN007
Parameters
Parameter
Value
Unit
Description
Note
Protocol
None
SpaBus
ProfibusDP
ModbusSla
ModbusTCPs
IEC-103
ExternalIO
DNP3
Protocol selection for the
rear panel local port.
Command line interface
for VAMPSET
SPA-bus (slave)
Profibus DB (slave)
Modbus RTU slave
Modbus TCP slave
IEC-60870-5-103 (slave)
Modbus RTU master for
external I/O-modules
DNP 3.0
Set
Msg#
0 ... 2
32
1
Message counter since the
device has restarted or
since last clearing
Clr
Errors
0 ... 2
16
1
Protocol errors since the
device has restarted or
since last clearing
Clr
Tout
0 ... 2
16
1
Timeout errors since the
device has restarted or
since last clearing
Clr
speed/DPS
Default =
38400/8N1 for
VAMPSET
Display of actual
communication
parameters.
speed = bit/s
D = number of data bits
P = parity: none, even, odd
S = number of stop bits
1)
VAMPSET communication (Direct or SPA-bus embedded command line
interface)
Tx
bytes/size
Unsent bytes in
transmitter buffer/size of
the buffer
Msg#
0 ... 2
32
1
Message counter since the
device has restarted or
since last clearing
Clr
Errors
0 ... 2
16
1
Errors since the device
has restarted or since last
clearing
Clr
Tout
0 ... 2
16
1
Timeout errors since the
device has restarted or
since last clearing
Clr
Set = An editable parameter (password needed)
Clr = Clearing to zero is possible
1) The communication parameters are set in the protocol specific menus. For
the local port command line interface the parameters are set in
configuration menu.
