Combined sticker, which is stuck to the
rear plastic cover.
("!N)
L Study the user manual before operating the machine.
M
Spark plug cable must be disconnected and battery removed from the battery
holder during machine maintenance.
N
Do not reach with your arm nor step with your leg into the cutting blade work space
– risk of cutting.
O
Risk of injury from chippings, cut-offs, flying objects, etc. Other persons and
animals - keep safe distance from the machine.
P Adhere to the machine’s maximum safety climbing ability when working.
V Guaranteed sound power level of the machine.
0!M
Separate sticker on the front plastic
cover.
("!V)
: Tool turning direction arrow – to the right (clockwise)
Sticker
("!S)
located on the work
tool side cover to the right, in terms of
the machine’s driving direction.
:
Restricted area for other individuals or pets. Minimum safe distance from the
machine is PR
Sticker
("!O)
on the control lever
on the right handle.
:
Turning on the cutting disc drive:
R = the cutting disk is not rotating
L = the cutting disc is rotating
Sticker
("!P)
on the control lever
on the left handle.
:
Turning on the machine wheel drive:
R = the machine is standing still
L = the machine is moving
0!N).1-"
3.3 BASIC INFORMATION
3.3.1 MACHINE USE
drum mower is designed and manufactured according to the most current knowledge in the field of small garden and
agricultural machinery. It is characterised by its easy handling, quiet, efficient and economy engine, as well as by trouble-free maintenance.
This mower is designed for cutting high-grown thin-bladed grass stands on maintained
75
areas maximum height of these is 60 cm.
There must be no solid objects in the stands or extensive surface unevenness. The mower is not designed for park grass stand care and for
mowing of stands with even minimum occurrence of self-seeding woody species
*.&&1-"&"&"."!
3.3.1.1 TECHNICAL INFORMATION
"- [ :PML :PML:PML :PML
Length mm 1755
Width (including the side screen) mm 779
Height mm 1130
Weight kg 57 59 / 61 58
Maximum cutting width cm 58,5
Safe climbing ability
10°
Cutting disk revolutions
76
min
-1
1964
Maximum blade circumferential velocity m.s
-1
60,9
Travelling speed km.h
-1
2,0
Area capacity
77
m2.h
-1
1170
Gearbox oil capacity l (litre) 0,05
Gearbox oil quality
API GL-4 (GL-5)
SAE 90 (80W-90)
0!O)0""%..:PML<:PML=
3.3.1.2 ENGINE INFORMATION
More information about the engine, not mentioned here, can be found at the internet site of the engine manufacturer.
SP
The vegetation on the area is cut and raked at least once a year!
SV
Actual rpm. of the disc when not cutting, including belt transmission losses.
SS
Square meters cut per min./hour will vary, depending on the type of the stand.
NP
Q#RSMRML
