Page #34 background image
INSTALLATION Series
642
34/107
Edition 2017-11-24 813316EB
Connector type: COMBICON 2.5 / 5 - ST – 5, 08 with special VAT housing
PIN
interface
connector
Signal Color of isolator (CC-Link wires) Comment
1 DA Blue Positive RS485 RxD/TxD
2 DB White Negative RS485 RxD/TxD
3 DG Yellow Signal Ground
4 SLD - Cable Shield
5 FG - Functional Ground
The CC-Link interface is galvanic isolated from control unit.
4.5.5.5 CC-Link network and cable
For detail information about «CC-Link cable, wiring and TR» refer to CC-Link
homepage:
http://www.cc-link.org
> «CC-Link Cable Wiring Manua
