4. Installing the Equipment: Base Stand (Optional)

48 PaX-i Plus / Insight Installation Manual

Martking Points on the Wall

1. Move the equipment to the installation site as close as possible.

2. Adjust the distance between the wall and equipment by moving it slightly, so that

the wall bracket touches the wall.

3. Mark four anchor bolt locations on the wall.

Marker n/a
