Vatech PaX-i Plus

4. Installing the Equipment: Base Stand (Optional)
PaX-i Plus / Insight Installation Manual 49
Drilling on the Wall
1. Drill the wall holes of size 10.5 mm x 30 mm (depth) using the concrete hammer drill.
2. Remove the debris and clean the holes using the dust pump.
3. Using the hammer, insert a Ficher strong anchor into the hole
Ficher strong
anchor
M8 x 30
(Part No. 34)
Hammer n/a
