5. Installing the Equipment: Wall Mount
68 PaX-i Plus / Insight Installation Manual
Combining the Equipment with the Anchor Bolts
1. Put the align plate on the floor while making sure that the align plate’s holes engage
in the anchored bolts.
2. Put the equipment in a vertical position slowly while holding the upper handle as
shown in the figure.
Be careful not to damage the cables before erecting the equipment.
Keep them clear of
the equipment.
