10
2. DESIGNATION
Note:
• Please refer to the illustration on page 3 (fold out) when reading this section.
11
11
1 p / FUNC (switch on / off / function)
button
22
22
2 VOL
8/28/2
8/28/2
8/2 (volume) and
SEARCH
44/6644/66
44/6644/66
44/66 buttons
33
33
3
66
66
6II (play / pause) button
4 Display
5 AS / SCN (Auto Store / scan function)
button
6 Release button for removable operating
panel
7 AF / RPT (alternative frequency / repeat)
button
8 PTY / RDM (programme type / random
play) button
9 SOUND (sound processor) button
0 INFO / TA (traffic announcement) button
a OPEN (extend LCD display) button
b DISP (switch display mode)
c Preset buttons (1 to 6)
d MUTE (mute function) button
e BAND (waveband) button
f LCD colour display
g AUDIO (audio mode) button
h ADJ (adjust) button
i TITLE (title) button
j WIDE (screen mode) button
k JOYSTICK (multifunction control)
l Infrared sensor
Retracted display Extended display
Button designation
