VDO MR6000 - Installation Instructions; Before Starting Installation; Packaging Contents

39
English
■ Contents
1. This unit is designed exclusively for use in
vehicles with a 12 volt system and negative
earth.
2. Please read these instructions carefully.
3. It is essential that the battery negative termi-
nal is disconnected before starting installa-
tion to prevent short circuits during installa-
tion (Figure 1).
1 Main unit
2 Instructions
Operating & installation instructions
3 Connecting cables
(power supply and loudspeaker)
4 Bag for main unit accessories (no. 1)
Countersunk screw (M5 × 8) ................... 4
Hexagon screw (M5 × 8) ........................... 5
5 Bag for main unit accessories (no. 2)
Hooked plate ............................................ 2
Cable clamp
Distance piece
Special screw
6 Universal mounting frame
7 Outer cover
8 Case for operating panel
1.BEFORE STARTING INSTALLATION
2.PACKAGING CONTENTS
Figure 1
Vehicle battery
1. BEFORE STARTING INSTALLATION ................................................. 39
2. PACKAGING CONTENTS.................................................................. 39
3. GENERAL PRECAUTIONS ................................................................ 40
4. PRECAUTIONS FOR INSTALLATION ................................................ 40
5. INSTALLING THE MAIN UNIT .......................................................... 41
6. REMOVING THE MAIN UNIT ........................................................... 42
7. PRECAUTIONS FOR WIRING ..............................................................43
8. WIRING CONNECTIONS ....................................................................44
9. EXAMPLE SYSTEMS ..........................................................................46
INSTALLATION INSTRUCTIONS
