Communication Setup - VaporTEK Interface Setup with Laptop
40
13. Debug Modes: Press 4
This sub-menu allows a debug mode selection. If fuel flow debug mode is selected the screen will show the
fuel flow rate when a transaction is running. Pressing ‘f‘ again will disable the flow debug mode. During flow
debug mode no other mode can be activated.
Once the VaporTEK Pump Unit starts running the fuel flow and the related motor speed information will be
shown on the screen. Press the ‘f’ button again to disable this function.
Press ‘s’ to show the power consumption data of motor.
New Connection Hyperterminal
File Edit View Call Transfer Help
Print echoCaptureNUMCAPSSCROLL9600-8-N-1Auto detectConnected 0:02:44
4. Debug Mode
-------------------
Press ‘f’ to toggle to real time fuel Flow
Press ‘d’ to debug Motor Hall Sensor Signals
Press ‘s’ to show the current Motor Speed
New Connection Hyperterminal
File Edit View Call Transfer Help
Print echoCaptureNUMCAPSSCROLL9600-8-N-1Auto detectConnected 0:02:44
************ Motor Data ***********
STATE SPEED POWER
RUN 0449 RPM 0013 Watts 0220 V(DC) 0064 mA(DC)
RUN 0481 RPM 0026 Watts 0219 V(DC) 0128 mA(DC)
RUN 0470 RPM 0019 Watts 0220 V(DC) 0096 mA(DC)
Motor Data off
Status 2 Idle
