Communication Setup - VaporTEK Interface Setup with Laptop
41
14. Show Calibration Table: Press ‘5’
Displays factory set calibration table when connected for the first time; thereafter shows the latest calibrated
table.
15. A/L – Ratio: Press ‘6’
Sub item 6 can be used to modify the A/L – Ratio. Set A/L – Ratio according to value which is mentioned on
the certificate as K-Factor (110%). NOTE: Set Speed Offset to ‘0’.
New Connection Hyperterminal
File Edit View Call Transfer Help
Print echoCaptureNUMCAPSSCROLL9600-8-N-1Auto detectConnected 0:02:44
5. Calibration Table
--------------------
MP Flow A Flow B Speed
[No] [l/min] [l/min] [rpm]
---------------------------
0 0 0 0
1 4 4 80
2 8 8 160
3 12 12 240
4 16 16 320
5 20 20 400
6 24 24 480
7 28 28 560
8 32 32 640
9 36 36 720
10 40 40 800
11 44 44 880
12 48 48 960
13 52 52 1040
14 56 56 1120
15 60 60 1200
New Connection Hyperterminal
File Edit View Call Transfer Help
Print echoCaptureNUMCAPSSCROLL9600-8-N-1Auto detectConnected 0:02:44
6. A/L - Ratio
------------------
Recover-Ratio Speed-Offset
101% 0
do you want to change it [Y/N]? Y
Recover Ratio = 101
new Ratio = 110
Speed Offset = 0
new Offset = 0
Data have been written successfully
Recover-Ratio Speed-Offset
110% 0
To Next Page
