WATER SUPPLY
The water used by the vending machine is drinking wa-
ter, taking into account the regulations in force where the
machine is installed.
Only models with water inlet solenoid valve.
The water pressure must be between 0.12 and 0.85 MPa
(1.2 - 8.5 bar).
Let the water come out from the mains until it is clear and
free from dirt.
Connect the water mains to the ” tting of the water
inlet solenoid valve by a pipe (also available in the kit)
suitable to withstand the water mains pressure, and of
a type suitable for food (minimum internal diameter of 6
mm.)
The water connection is located under the machine.
To connect the machine to the water mains use only
Do not reuse the material that may exist.
Installing a tap on the water system outside the ma-
1
Fig. 16
1- ¾” inlet water solenoid valve fitting
Only models without water inlet solenoid valve.
;
the kit is accompanied by instructions for assembly and
testing that must be strictly observed to maintain safety
of the machine.
Place the tank in a clean and protected location (closed
cabinet), convenient for lling and periodic cleaning.
Important
Using kits that have not been approved by the manufac-
turer does not guarantee the compliance with the safety
standards, especially for what concerns live-parts.
The manufacturer declines any responsibility for the use
of non-approved components.
The installation and the subsequent test operations
both from the point of view of electrical safety and
of hygiene.
