VendCo KARISMA - Table of Contents

© by N&W GLOBAL VENDING S.p.A. 1 02-2014 4535 00
English
TABLE OF CONTENTS
PAGE
PAGE
dEclaration of conformity
warnings
FOREWORD 2
dEvicE idEntification and fEaturEs 2
in casE of failurE 2
transport and storagE 2
machinE positioning 3
tEcHNical cHaractEristics 3
powEr consumption 4
accEssoriEs 4
CLEANING AND LOADING 5
main switch and safEtiEs 5
hygiEnE and clEaning 5
usE of hot bEvEragE dispEnsErs in opEn containErs 6
coNtrols aND iNformatioN 6
loaDiNg proDucts 7
coffEE bEans 7
instant products 7
milk 7
intErnally suppliEd tank watEr 7
macHiNE saNitizatioN 8
ground trays prEsEnt 8
mixEr clEaning 9
clEaning nozzlEs and spouts 10
coffEE unit clEaning 10
clEaning of thE milk tank 10
intErnally suppliEd watEr tank clEaning 10
start-up 11
wasH cyclEs 11
milkEr rinsE 11
cappuccino makEr wash 12
infusEr unit wash cyclE 14
wash functions 15
touchscrEEn clEaning 15
sErvicE suspEnsion 15
INSTALLATION 16
main switch and safEtiEs 16
unpacking thE machinE 16
watEr supply 17
solid and liquid rEsiduEs dischargE 18
ElEctrical connEction 18
rEmoving thE sidE and rEar panEls 20
sidE modulEs installation 20
dEscalEr 21
first start-up 21
milk pump calibration 21
first sanitization 22
opEratioN 22
EsprEsso unit 22
variablE-dosE coffEE dosEr 23
milk dElivEry 24
cappuccino makEr wash cyclEs 25
stEam dispEnsing from spout 25
hot watEr dispEnsing from spout 25
machinE lighting 25
chEcks and sEttings 26
PROGRAMMING 27
EntEring thE programming modE 27
browsing modE 28
start-up 28
opEration in normal usEr status 29
maNagEr mENu 29
ENgiNEEr mENu 30
sElEctions 30
display 33
machinE sEtup 33
calibration 35
diagnostics 36
countErs 39
wasH mENu 40
wash status 40
touchscrEEn clEaning 40
usb mENu 41
sEtup / graphics 41
statistics 41
MAINTENANCE 42
gEnEralitiEs 42
main switch and fusEs 42
EsprEsso unit maintEnancE 43
pErioDical opEratioNs 44
sanitization 44
rEmovE thE product containErs 47
rEmoving thE sidE and rEar panEls 48
ElEctroNic boarD, rElay, aND solENoiD valvE
fuNctioNs 48
cpu activation board 49
switching powEr supply board 50
hydraulic circuit solEnoid valvEs 50
boilEr thErmal protEction 52
softwarE updatE 53
APPENDIX 55
