New Configuration
Ver-Mac 2018 V-Touch Controller for TLDs User Manual – V3.2 49
9 New Configuration
New Configuration allows you to program the signalization system according to the
combination of traffic signal units that control the intersection. Because configuration is
specific to each individual unit, you must configure each unit separately and in numerical
order.
New Configuration in the Options screen enables you to:
Configure the system for a new intersection.
Alter/change the factory settings of the Ver-Mac TLD units operating at a
particular intersection.
Figure25: Options menu showing New Configuration button
1. In Options screen, tap to select New Configuration and confirm (Yes).
2. Check the TLD unit number displayed on the information screen on the control
panel to be sure the V-Touch Controller is plugged into TLD Unit#1.You must be
plugged into Unit #1 in order to proceed.
3. If you are at Unit #1, tap OK to continue and begin the configuration.
4.
