New Configuration
Ver-Mac 2018 V-Touch Controller for TLDs User Manual – V3.2 54
1. In the device list, Area 1 is the master or the current unit, you will only need to
assign the second device to Area 2:
2. Select the device in the list.
3. Select the Area 2 button. At the bottom, you should have the mention Area 1 =
1 Area 2 = 2.
4. Once configuration is complete, Shutdown when prompted.
You can now proceed to operate the signalization for the intersection or create the
signalization cycles to enable the TLD units at the intersection to function.
NOTE
If you are using GPS synchronization, refer to section 6.5.1 to get the
profile codes and enter them in each traffic signal.
