TERMINAL SETUP
Examining Terminal Features
18 VX 680 INSTALLATION GUIDE
Examining
Terminal
Features
Before you continue the installation process, notice the features of the
VX 680 terminal (see Figure 2).
Figure 2 VX 680 Terminal Features (Front Panel)
9;

;
§
§
MAGNETIC CARD
TELEPHONE-STYLE
KEYPAD
CLEAR KEY
SMART CARD READER
INDICATOR LED
INTERNAL THERMAL
PRINTER (AT THE BACK)
TERMINAL DISPLAY / TOUCHSCREEN
STYLUS
ENTER KEY
CANCEL KEY
READER
