GENERAL SPECIFICATIONS
Note: The specifications listed in this chapter are subject to change without
notice.
7.0/ GENERAL SPECIFICATIONS
Model Number: XC46BE
Technical Standard: 3GPP Release 16 (DL CAT 19, UL CAT 18)
Frequency band: LTE Band: B2,B5,B13,B48,B66,
DL 4x4 MIMO, UL 1x1 SISO
5G Band: n2, n48, n66, n77: DL 4x4 MIMO,
UL 2x2 MIMO; n5: DL 4x4 MIMO, UL 1x1
MIMO
Wi-Fi Standard: 802.11 a/b/g/n/ac/ax/be
Dimensions: 140 mm x 140 mm x 220.5 mm (L x W x H)
Weight: 1.15 Kg
Certifications: FCC, UL
Operating Temperature: 5° C to 40° C (41° F to 104° F)
Storage Temperature: -45° C to 70° C (-49° F to 158° F)
Operating Humidity: 5% to 90%
Storage Humidity: 5% to 95% (non-condensing)
7.1/ CONNECTIONS
DC Input: source adapter: 12V/3.5A
Battery: 70.56Wh
Ethernet: RJ-45 Gigabit
LAN Ports 2 x 1G
WAN Port 1 x 2.5G, PoE802.bt (Secondary
Power)
