BUTTON FUNCTION
Name Name of device
EID Unique EID in a module
Port The port to which a device is connected
Clear Clear all offline IQ modules
Disconnect Disconnect the KVM session
Setup Access the Setup dialog box and configure the OSCAR interface
Commands Access the Commands dialog box
VMedia Control virtual media connection
Table 3.1 Main Dialog Box Functions
3.1.2 Viewing switch system status
The status of devices in your system is indicated in the right column of the Main dialog box. The following
table describes the status symbols.
