SETTING DESCRIPTION
CD ROM/
DVD ROM
Allows virtualmedia sessions to the first detected CD-ROM or DVD-ROM (read-only) drives. Enable this checkbox to
establish a virtual media CD-ROM or DVD-ROM connection to a device. Disable to end a virtual media CD-ROM or DVD-
ROM connection to a device.
Mass
Storage
Allows virtualmedia sessions to the first detected mass storage drive. Enable this checkbox to establish a virtual media
mass storage connection to a device. Disable to end a virtual media mass storage connection to a device.
Table 4.5 Local Virtual Media Session Settings
4.13 DSView™ Software Settings
NOTE: User account settings are supported when the Dell® RAK is installed.
You can contact and register an unmanaged switch with a DSView™ management software device by
specifying the IP address of the management software device.
To configure the device IP address:
1. On the side navigation bar, select User Accounts - DSView. The DSView™ Authentication
Servers screen is displayed.
2. Enter the device IP addresses that you want to contact. Up to four addresses are allowed.
3. Use the scroll bar to select the desired retry interval.
4. To disassociate the switch that has been registered with the device, click the Disassociate
button.
5. Click Save.
4.14 Active Sessions
From the Active Sessions screen, you can view a list of active sessions and the following information about
each session: target device, owner, remote host, duration and type.
4.15 Closing a Session
To close a session:
1. From the side navigation bar, select Active Sessions to display the Appliance Active Sessions
screen.
2. Click the checkbox next to the desired target device(s).
3. Click Disconnect.
NOTE: If there is an associated locked virtual media session, it is disconnected.
To close a session (local users only):
1. From the side navigation bar, select Local Session.
2. Select the Disconnect Active Session checkbox.
Vertiv™ | Avocent® AutoView ™ Switch for Dell Installer/User Guide
40
