Vertiv Liebert CW Series User Manual

Document Number Title
PlanningDimensions-Plenumsfor UnitswithECFans
DPN004604 PlenumDimensional Data, DownflowModels, CW038toCW084
DPN004605 Plenum Dimensional Data, DownflowModels, CW106andCW114
DPN003214 Plenum Dimensional Data, UpflowModels, CW038toCW084
DPN003213 PlenumDimensional Data, UpflowModels, CW106andCW114
PlanningDimensions-Plenumsfor UnitswithForward-curvedBlowers
DPN003204 PlenumDimensional Data, UpflowModels, CW038toCW084
DPN003205 Plenum Dimensional Data, UpflowModels, CW106andCW114
PipingSchematics
DPN004561 PipingSchematic, Downflow, CW038toCW114
DPN004138 PipingSchematic, Downflow, CW146andCW181
DPN004562 PipingSchematic, Upflow, CW038toCW114
PipingConnections-DownflowUnitswithECFans
DPN002036 ConnectionLocations, CW038toCW041
DPN002035 ConnectionLocations, CW051 and050
DPN002034 ConnectionLocations, CW075 toCW084
DPN001628 ConnectionLocations, CW106andCW114
DPN001693 ConnectionLocations, CW146andCW181
DPN002434 ConnectionLocations, CW300andCW400
PipingConnections-UpflowUnitswithForward-curvedBlowers
DPN001668 ConnectionLocations, CW038toCW084
DPN001669 ConnectionLocations, CW106andCW114
ElectricalConnections-DownflowUnits
DPN004548 Electrical FieldConnections, DownflowCW038toCW084
DPN004549 ElectricalFieldConnections, Downflow, CW106, andCW114
DPN004550 Electrical FieldConnections, Downflow, CW146andCW181
ElectricalConnections-UpflowUnits
DPN003200 High-voltage Connections, Upflow, CW038toCW084
DPN004552 Low-voltage andEthernetConnections, Upflow, CW038toCW084
DPN003202 High-voltage Connections, Upflow, CW106andCW114
DPN004551 Low-voltage andEthernetConnection, Upflow, CW106andCW114
Unit-to-Unit Networking
DPN004351 Liebert®iCOMUnit-to-unit Network Connections
Table B.1 Submittal-drawings Contents (continued)
Vertiv | Liebert® CW™Installer/User Guide
