Vertiv Liebert CW Series User Manual

Figure 7.5 EC-fan assembly
Item Description Quantity
Not shown Washer 6
Not shown Bolt 6
Not shown Spacer 6
Table 7.4 EC Fan Parts and Quantities
Compressor-plenum Parts Identification
Assembly no. andweight Plenum size, in. (mm)
313202G10-27 lb(11 kg) 17 x 24(432 x 610)
313202G11 -30 lb(14kg) 17 x 30 (432 x 762)
313202G12 -33 lb(15 kg) 17 x 36(432 x 914)
Table 7.5 Compressor Plenum Assembly Numbers, Weights and Size
6 ECFans and Plenums
49
