REV : 2
REV DATE : 6/18
DPN004351
Page :1 /2
Form No.: DPN001040_REV4
UNIT TO UNIT NETWORK CONNECTIONS
LIEBERT DS, DSE, CW, PDX & PCW
TO / FROM OTHER
NETWORKED UNITS
TB3
P71 P72
P74 P64
E5
P
6
7
P
6
6
P
1
1
P
1
2
P
2
1
P
2
0
P
1
3
P
7
P76
P95
P100
P75
2
RS485
ETHERNET
SITE AND BMS
COMMUNICATION
CONNECTIONS
iCOM
MICROPROCESSOR
AND I/O BOARD
ETHERNET CABLE
(FIELD SUPPLIED)
TB3
P
2
DETAIL A
-
1 2
A
UNIT-TO-UNIT NETWORKING SWITCH
(FIELD SUPPLIED)
+
P95 DVI-D CABLE CONNECTION
TO 7-INCH ICOM DISPLAY
P100 POWER SUPPLY TO
7-INCH ICOM DISPLAY
