Vertiv Liebert CW Series User Manual

5. Attachthe bottom of the channel frame(s) tothe top of the unit using 1 washer and 1 bolt for each, Figure 7.22
below.
Figure 7.22 Channel frame bottom attachment
Item Description
1 Bolt
2 Washer
3 Channel frame
4 Bolthole/Hexsert
5 Front of unit
Vertiv | Liebert® CW™Installer/User Guide
66
