Figure 7.15 Junction box between fans 1 and 2
NOTE: For the high-volt terminal blocks, the wire-termination torque is 16-20in-lbs.
Item Description
1 Fan(low-volt)wiring
2 Motor(high-volt)wiring
3 Green/Yellowgroundwire
6 ECFans and Plenums
59
