6. For non-grilled plenums, refer to Figure 7.23 belowand attachthe plenum brace to the top frame and the rear
panel using 2 sheet-metal screws oneachend.
Figure 7.23 Non-grilled plenum plenum-brace attachment
Item Description
1 Topframe
2 Sheet-metal screws
3 Plenum brace
6 ECFans and Plenums
67
