Uponarrival of the unit and before unpacking:
Verify that the labeled equipment matches the bill of lading.
Carefully inspect all items for visible or concealed damage.
Report damage immediately to the carrier and file a damage claim witha copy sent toVertiv or to your sales
representative.
For initial access use a 7/32-in. Allen wrench for panel removal.
Equipment Recommended for Handling the Unit:
Forklift
Pallet jack
Pianojacks
Lift beam
Slings
Spreader bars
3.1 Packaging Material
All material used to package this unit is recyclable. Please save for future use or dispose of the material appropriately.
3.2 Handling the Unit while Packaged
ransport the unit with a forklift or pallet jack. If that is not possible, use a crane withslings and spreader bars that are rated
for the weight of the unit.
When using a forklift or pallet jack:
Ensure that the fork lengthis suitable for the unit lengthand, if adjustable, spread tothe widest allowable
distance that will fit under the skid.
When moving the packaged unit, lift the unit from the end withthe indicated labeling, and do not lift the unit
any higher than4in. (102 mm). Ensure that the opposite end of the skid still touches the floor. The unit must be
pulled by the forklift. All personnel except those moving the unit must be kept 12ft (3.7m) or more from the
unit while it is being moved.
If the unit must be lifted higher than 4in. (102 mm), all personnel not directly involved inmoving the unit must
be 20ft (5m) or farther from the unit.
OnCW146 throughCW400 models, Always refer to the locationof the center-of-gravity indicators when lifting
the unit, see Figure 4.1 below.
Figure 4.1 Center-of-gravity indicator
Vertiv | Liebert® CWInstaller/User Guide
24
