Digit Description
Digit8= FanType
S= Forward-curvedblower withstandardmotor
V= Forward-curvedblower withvariable-speeddrive
1 = ECfan
H= ECfanwithTHD
Digit9= Voltage
A= 460V-3ph-60Hz
B = 575V-3ph-60Hz
C= 208V-3ph-60Hz
D= 230V-3ph-60Hz
2 = 380V-3ph-60Hz
F= 380V-3ph-50Hz
G= 415V-3ph-50Hz
M= 380-415V-3ph-50Hz
Digit10 =ValveType
1 = 2-way valve, highpressure
T= 3-way valve, highpressure
Digit11-14= Factory ConfigurationNumber
Digit15= ConfigurationCode
A-Z = Standardconfiguration
S= SFA
Table 2.2 CW Model-number Digit Definitions (continued)
Not all combinations of options are available on all units:
• Models CW146, CW181, CW300, and CW400 only available indownflow configuration.
• Disconnect switch, Locking
• Not available on 208-V units with20-hp motor
• Flow switch that activates the warning system
• Ships loose
• Humidification and Reheat
• Not available on CW300 and CW400
• Steam/Hot-water reheat package
• Not available on units with EC fans
Vertiv | Liebert® CW™Installer/User Guide
12
