PLENUM DIMENSIONAL DATA
LIEBERT CW
UPFLOW MODELS CW106 - CW114 W/ FORWARD CURVED BLOWERS
C
D
K
B
1"
25mm
1"
25mm
1"
25mm
2"
51mm
C
D
2"
51mm
Flange is standard on all Upflow units
Both top duct openings and
front grills are shown. See
specification sheet for specific
application.
A
E
J
18"
457mm
F
G
H
L
Note: Flanges provided
on blower(s) outlet for
supply air ducting when
solid panel plenum is used.
E
2"
51mm
1"
25mm
K L
20 (508) 1 (25)
22-3/4 (578)
34-3/4 (883)
Plenum Height in. (mm)
2-3/8 (60)
A B C D E F G H J
122 (3099) 34 (864) 118 (2997) 32 (813) 44 (1118) 3-1/2 (89) 4 (102) 7 (178) 16 (406) 10.14 (0.94)
Plenum Dimensional Data in. (mm)
Grill Free Area Sq.
Ft. (Sq. Meters)
