Vertiv Liebert CW Series User Manual

REV : 4
REV DATE : 10/18
DPN003214
Page :1 /1
UPFLOW MODELS CW038 - CW084 W/ EC FANS
Form No.: DPN001040_REV4
PLENUM DIMENSIONAL DATA
LIEBERT CW
C
G
B
F
E
A
D
C
D
20"
508mm)
2"
(51mm)
(25mm)
1"
1"
(25mm)
2"
(51mm)
(25mm)
1"
(25mm)
1"
(51mm)
2"
SUPPLY AIR G
GRILLE & T OP DISCHARGE 22.75 (578)
TOP DISCHARGE ONLY 30 (762)
TOP DISCHARGE ONLY 36 (914)
PLENUM HEIGHT DATA in (mm)
MODEL A B C D E F
CW038, CW041 50 (1270) 46 (1168) 46 (1168) 2 (51) 4.29 (.40)
CW051, CW060 74 (1880) 70 (1778) 62 (1575) 6 (152) 5.85 (.54)
CW076, CW084 99 (2515) 95 (2413) 70 (1778) 14 1/2 ( 368) 6.83 (.63)
GRILL FREE
AREA SQ. FT.
(SQ. METERS)
PLENUM DIMENSIONAL DATA in (mm)
34 (864) 32 (813)
TOP DUCT FLANGES ON
PLENUM TOP FOR SUPPLY AIR
DUCTING WHEN SOLID PANEL
PLENUM IS USED.
BOTH TOP DUCT OPENINGS AND
FRONT GRILL ARE SHOWN. SEE
SPECIFICATION SHEET
FOR SPECIFIC APPLICATION.
2"
(51mm)
Shaded area indicates a recommended CLEARANCE
OF 36" (914mm) be provided for EC Fan Plenum access
from the bottom of the unit to the top of the plenum.
See DPN003215 for unit clearances.
