60
Maintenance
> Check that the cutterbar is roughly horizontal both longitudinally
and in the direction of travel. Correct the cutterbar's position by ad-
justing the top link on the machine.
> Locate the oilplug on the cutterbar and remove it.
• With warm oil: Wait approx. 3 minutes.
• With cold oil: Wait approx. 15 minutes.
• Check the oil level as shown and refill if necessary.
→ »Lubricants« Page 97.
→ »Maintenance intervals« Page 55.
> Fit the oilplug.
> Close the guard around the machine's cutterbar.
> Fit the ring nut and fasten it.
Min. 7 mm
Max. 11 mm
Ring nut
