74
Maintenance
If there are loose bolts the following procedure should be followed:
> Remove and clean the bolts.
> Apply Loctite 242 to the bolts.
> Mount and tighten up the bolts.
→ »Torque moment« Page 97.
> Fit the cone cover and fasten it.
> Fit the protection around the PTO shaft.
> Close the guard around the machine's cutterbar.
> Fit the ring nut and fasten it.
Ring nut
