3 Installation
3.1 Installation and Start-Up
Installation and start-up of the laser system requires extensive knowledge and ex-
perience. Therefore it should be accomplished by personnel of Videojet Technol-
ogies Inc. or one of their representatives only.
In order to facilitate quick and easy start-up please prepare the place of installa-
tion such that the system can be installed:
• Proceed as described in section "Unpacking [} 19]".
• Please provide all connections - as described in section "Installation Condi-
tions" and in the documents you received upon order handling - prior to instal-
lation.
In case of questions please contact Videojet Technologies Inc..
NOTICE
The company operating the laser system is responsible for the safe use of the la-
ser system, especially for meeting the local codes and regulations regarding the
operation of laser systems and their components (beam protection, fume extrac-
tor, cooling, etc.).
Videojet Technologies Inc. does not accept responsibility for any damage due to
misuse of equipment, incorrect operation or negligence.
The supply unit is connected to the marking unit via a disconnectable supply line.
The disconnectable supply line connector is mounted on the marking unit and it is
fixed with two fixing screws.
Using high-quality connectors with gold-plated plug contacts a high number of
mating cycles (minimum 200) is achieved. This corresponds to a normal industrial
usage. An increased number of mating cycles may lead to wear.
NOTICE
When the supply line is to be disconnected/connected, the laser system must be
completely switched off.
09/17 - Index: AD [EN]
18
Videojet 3140/3340/3640/3 Installation
