VIDEOJET 3140 - Safety Circuit of the Laser System (60 W)

8.2 Safety Circuit of the Laser
System (60 W)
The safety circuit is realized via connector X9 on the SPM board.
Position of the board in the laser system:
Position X9:
The laser system can be ordered in 2 variants:
1. With safety circuit according to EN 13849-1, achieving performance level "d"
for the interlock circuit.
2. With safety circuit according to EN 13849-1, achieving performance level "d"
for the door circuit and performance level "e" for the emergency stop circuit.
09/17 - Index: AD [EN]
63
Videojet 3140/3340/3640/8 Appendix
