VIDEOJET 3140 - Fuses

4.7.1 Fuses
Name Size in mm Position
8 A / 250 V / T (time delay) ∅ 5 x 20 at the back of the supply unit, IP
sealing must be removed, see I9 in
section Elements on the Supply Unit
(only 10/30 W)
1.6 A / 250 V / T (time de-
lay)
∅ 5 x 20 in the supply unit, at the internal ca-
bles of the connection for Handheld
and Touch PC I3 (transparent fuse
holder), see I3 in section Elements
on the Supply Unit
13 A / 250 V ∅ 6.3 x 25.4 inside mains plug (only for UK)
NOTICE
For 60 W laser systems:
In case of a short circuit the device uses the electrical protection of the building.
09/17 - Index: AD [EN]
31
Videojet 3140/3340/3640/4 Description of the Laser System
