Unit Videojet 3140 Videojet 3340 Videojet 3640
Focal length of
laser scan lens
• SHC 60D
• SHC 100D/SHC 120C
• SHC 150C
mm
64; 95; 127; 190; 254
63,5
b
; 85
b
; 100; 150; 200; 300; 351; 400
100; 150; 200; 300; 351; 400; 500; 600
Focus diameter (min.) µm 70
(depending on installed optics)
Line width depending on the material and the laser parameters
Fonts any standard font (special characters on demand for additional
charge)
Cooling integrated air-cooling
maximum distance marking
unit - supply unit
m 3, 5 or 10
(others on demand)
Min. bending radius of sup-
ply line
mm 150
Interfaces Network interfaces, I/O interfaces
Control Handheld and/or Windows-compatible PC with Smart Graph soft-
ware, Touch PC or CLARiTY Laser Controller
a.
Any statements referring to marked characters or actual markings are typical
values. These values highly depend on the material and may only be taken as a
guideline. These are no specifications!
b.
Only 10/30 W
Due to Videojet Technologies Inc.'s policy of continuous improvement, technical
data is subject to change without notice.
