I/O Customer interface
(standard)
The general assignment of the customer interface
can be found in chapter "Appendix".
The customer-specific assignment of the custom-
er interface can be found in the data sheets you
received upon order handling.
I/O Backplate with connec-
tors
(optional)
Interlock
The interlock circuit is used to safeguard the laser
system. If one of the interlock switches connected
to the interlock circuit opens the marking stops im-
mediately. The marking cannot be continued until
all interlock switches are closed and the START
button is pressed.
An option is available for increasing the perform-
ance level of the interlock circuits.
Trigger
The laser system has one trigger input port to
connect a light barrier for product detection. The
trigger input port is supplied with +24 V.
Encoder
An encoder can be connected to the encoder in-
terface for movement detection. The laser system
provides +24 V for the encoder.
Fume extractor
Connection for a fume extractor.
Beacon
Connection for a beacon.
RS232
Connection for the control of the laser system.
3.8 Definition of the IP Address
When the laser system is delivered the following IP address is set:
Standard IP: 192.168.1.1
Subnet mask: 255.255.255.0
A different IP address can be configured via the software.
09/17 - Index: AD [EN]
23
