Assignment Variant 1 (SPM-16A)
NOTICE
Assignment Variant 1 guarantees performance level "d" according to EN13849-1
for the interlock circuit. Prerequisite is the correct wiring of the interlock circuit us-
ing appropriate safety switches and cables:
For the interlock switches positively opening contacts according to IEC60947-5-1
must be used (e.g. SCHMERSAL AZ 16-02ZVRK). The supply lines must have
individually shielded cores (e.g. HELUKABEL LiY-TPC-Y (4x2x0.5 or 2x2x0.5) P#
21357 or 21355.
The MTTF calculation used for achieving performance level "d" is based on the
following assumptions:
1) Number of operating hours/day = 21 (3 shift operation with 1 hour break)
2) Number of operating days/year = 310 (365 days minus sundays/holidays)
3) Cyle time in seconds = 28,800 (8 hours 3 shift operation with 1 cleaning cycle
per shift)
4) Resulting average number of cycles per year = 813.75
Terminal Signal In/Output Description
X9.1 24V_INT Output see X9.23
Default: Bridge to X9.23
X9.2 GND_INT Output -
X9.3 24V_LAS Input -
X9.4 GND_INT Output -
X9.5 24V_INT Output -
X9.6 - Output reserved
X9.7 24V_INT Output -
X9.8 - Output reserved
X9.9 GND_INT Output -
X9.10 - Input Bridge to X9.12
X9.11 GND_INT Output
X9.12 - Output Bridge to X9.10
X9.13 GND_LAS Input
X9.14 SHUTTERLOCK 1 Input If one of the shutterlock circuits is
opened, the beam shutter of the la-
ser is closed immediately.
Connect to X9.7 to close the shut-
terlock.
Default: Bridge to X9.7
X9.15 INTERLOCK 2 Input If one of the interlock circuits is
opened, the laser power supply is
switched off immediately.
Connect to X9.19 to close the inter-
lock.
Default: Bridge to X9.19
09/17 - Index: AD [EN]
64
Videojet 3140/3340/3640/8 Appendix
