Terminal Signal In/Output high/low Description
X22.1 reserved Input reserved for internal pur-
poses
X22.2 LA-
SER_READY
Output high This signal is set as
soon as the key switch
is closed and the laser
source was initialized
successfully. If high, the
system accepts start sig-
nals for starting a mark-
ing process.
X22.3 reserved Input falling
edge
reserved for internal pur-
poses
X22.4 MARKING Output high This signal is set during
the marking process.
X22.5 START_MARK
ING
Input high This signal starts the
marking process, if
STOP_MARKING is not
active.
X22.6 READY_TO_M
ARK
Output high This signal is set as
soon as all necessary
data and START signal
have been received
(waiting for trigger).
X22.7 STOP_MARK-
ING
Input low This signal stops the
marking process and
prevents
START_MARKING if ac-
tive.
X22.8 SHUT-
TER_CLOSED
Output high This signal is set if the
beam shutter is closed.
X22.9 reserved Input reserved for internal pur-
poses
X22.10 GND_CI Output
X22.11 +24V_CI Output
X22.12 GND_CI Output
09/17 - Index: AD [EN]
75
Videojet 3140/3340/3640/8 Appendix
