Measures
1. Replace CR2032 battery in HPMU electronics mod-
ule.
2. Set the time on the HMI programming unit: See
operating instructions.
F.430 Communication error, gateway
F.430
System characteristics
Operation with internal set value specifications of the
heat pump control unit
Cause
Gateway (WAGO KNX/TP) communication error
Measures
1. Check system configuration for gateway: CAN bus
subscriber number 90
2. Turn off the ON/OFF switch on the indoor unit. Wait
at least 2 min. Turn on the ON/OFF switch.
3. Check the CAN bus connections:
■
Connections X8.1 to X8.3 on plug 91 on
the HPMU electronics module
■
Wall mounted indoor unit:
Connection on device underside, 6-pole connec-
tion socket on the left, terminals 1.CAN L to
3.CAN H
Floorstanding indoor unit:
Connection to luster terminals for BUS connec-
tions, terminals 91.CAN L to 91.CAN H
■
Check wires and plugs for correct seating.
■
Check connections for contact corrosion.
■
Check cables for mechanical damage, e.g. crush-
ing, kinking, chafing or breakage.
■
Check CAN L/CAN H assignment.
■
CAN Ground (GND) must not be connected.
■
Check cable type: Li2YCYv, twisted pair, shielded
or 2-core CAT5, shielded
■
Check cable length.
■
Check the position and number of terminators.
4. Replace CAN bus Gateway cable.
5. Check power supply to the gateway.
6. Replace gateway.
F.431 Communication error, KNX
F.431
System characteristics
No communication with building management system
Cause
Internal fault on gateway (WAGO KNX/TP)
Measures
1. Check system configuration for gateway: CAN bus
subscriber number 90
2. Turn off the ON/OFF switch on the indoor unit. Wait
at least 2 min. Turn on the ON/OFF switch.
3. Replace gateway.
