VIPA CPU Series User Manual

Manual VIPA System 200V Chapter 2 Hardware description
HB97E - CPU - RE_21x-1Bx06 - Rev. 13/20 2-3
Structure
[1] Operating mode switch
[2] LEDs of the CPU
[3] Slot for MMC
memory card
[4] MP
2
I interface
Front view
CPU 21x
PW
SF
FC
MC
CPU 21x
DC
24V
+
-
1
2
RN
ST
MR
X1
MMC
4
5
3
2
1
R
S
X2
34
VIPA 21x-1Bx06
M
P
I
2
[5] Slot for DC 24V
power supply
MP I
2
5
4
3
2
1
9
8
7
6
reserved
M24V
RxD/TxD-P (line B)
RTS
M5V
P5V
P24V
RxD/TxD-N (line A)
n.c.
1
2
3
4
5
6
7
8
9
1
2
+ DC 24 V
0 V
+
-
X1
Interfaces

VIPA CPU Series Specifications

General

Series	VIPA CPU Series
Communication Ports	Ethernet
Power Supply	24 V DC
Operating Temperature	0°C to +60°C
Certifications	CE, UL, cUL
