Manual VIPA System 200V Chapter 1 Basics and Assembly
HB97E - CPU - RE_21x-1Bx06 - Rev. 13/20 1-5
Dimensions
1tier width (HxWxD) in mm: 76 x 25.4 x 74
2tier width (HxWxD) in mm: 76 x 50.8 x 74
80 mm
60 mm
74 mm
88 mm
ca. 110 mm
84 mm
85 mm
76,62 mm
76 mm
2,77 cm
24 mm
Dimensions
Basic enclosure
Installation
dimensions
Installed and wired
dimensions
In- / Output
modules
