Chapter 2 Hardware description Manual VIPA System 200V
2-6 HB97E - CPU - RE_21x-1Bx06 - Rev. 13/20
Technical Data
Order no. 214-1BC06
Type CPU 214C
Technical data power supply
Power supply (rated value) DC 24 V
Power supply (permitted range) DC 20.4...28.8 V
Reverse polarity protection
9
Current consumption (no-load operation) -
Current consumption (rated value) 1.5 A
Inrush current 65 A
I²t 0.75 A²s
Max. current drain at backplane bus 3 A
Power loss 3.5 W
Load and working memory
Load memory, integrated 80 KB
Load memory, maximum -
Work memory, integrated 48 KB
Work memory, maximal -
Memory divided in 50% program / 50% data -
Memory card slot MMC-Card with max. 512 MB
Hardware configuration
Racks, max. 4
Modules per rack, max. total max. 32
Number of integrated DP master -
Number of DP master via CP 8
Operable function modules 32
Operable communication modules PtP 32
Operable communication modules LAN -
Status information, alarms, diagnostics
Status display yes
Interrupts no
Process alarm no
Diagnostic interrupt no
Command processing times
Bit instructions, min. 0.18 µs
Word instruction, min. 0.78 µs
Double integer arithmetic, min. -
Floating-point arithmetic, min. -
Timers/Counters and their retentive
characteristics
Number of S7 counters 256
Number of S7 times 256
Data range and retentive characteristic
Number of flags 8192 Bit
Number of data blocks 2047
Max. data blocks size 16 KB
Max. local data size per execution level 1024 Byte
Blocks
Number of OBs 14
Number of FBs 1024
Number of FCs 1024
Maximum nesting depth per priority class 7
Maximum nesting depth additional within an error
OB
1
214-1BC06
