1. Overview
1.1 Package Contents
The device package contents consist of the following:
Note
Please check all components involved.
Table 1-1 Package contents
No
Name
No
Name
1
NVR
4
DC Power supply
2
CD (Manuals and Client software)
5
Quick guide
3
Mouse
1.2 Part Description
Each part is listed in the below:
Figure 1-1 Name and Connection of each front section
Table 1-2 Name and Function of each front section
No.
Name
Function
1
PWR
Illuminated when power is on
2
REC
Illuminated if recording is in progress
3
PB
Illuminated if playback is in progress
4
NET
Illuminated if connected via network
5
IR Remote Control
Sensor
Receives all incoming signals from the remote control.
6
USB port
For connection of Mouse and USBdrives for download and firmware
upgrading
4ch NVR
