Features Description
1 = LCD Display Displays information about telephone status, dialing
directories, and test message information.
2 = Handset Device used to listen/speak when on a call in handset
mode.
3 = Headphone When using a headphone, this button toggles the
headphone state.
4 = Speaker Device used to listen to a caller in a handsfree mode
when in speaker mode.
5 = Speaker Button Speaker toggles speakerphone state between speaker
mode and handset mode. The button is red when
speakerphone is active.
6 = Hold/Save Button This button is used to hold calls and to retrieve held
calls.
7 = Volume The volume button adjusts the level of tones,
background music, ringing, and receiver volume
8 = MSG LED This button illuminated to indicate you have a message
waiting.
9 = Flexible Buttons The 8 flexible buttons are used to access outside lines or
call-handling features.
10 = Speed Button Used to access speed dialing, save number redial, and
last number redial. Also used to access flexible button
programming.
11 = Trans/PGM Button This button is used to stransfer intercom or outside call
from one station to another.
12 = MIC Microphone used to speak to a caller in a handsfree
mode when in speaker mode.
